Product Overview：
Single Jaw Elastomer Coupling is the one of the most widely used types of industrial transmission, which we have precision machining for controlling the tolerance of the bore, keyway, and end-face run-out that ensures a tight and reliable fit with the shaft.
Either one of the two types of steel, carbon steel or alloy steel, is used to make the metal hubs and the heat treatment option is also available to increase the strength and wear resistance.
The spider is made of an elastomer and can be of different hardness levels. The conditions for normal temperature, high temperature, oil, and wear resistance are some of the cases for which the spider material can be chosen accordingly.
Product Advantages:
In addition the coupling features a compact design, an Installation without problems, and minimal maintenance, therefore, it can be regarded as a small, reliable medium-power transmission system source with a choice of low power levels.
Because of the highly accurate machining the installation Is facilitated and no further adjustments Are necessary: the bore, the keyway, and the runout are all tightly controlled according to the industrial standards.
There is a wide range of top-quality elastomers: three main variants - wear-resistant, high-temperature, and oil-resistant materials, which can be used for different conditions and purposes.
Dynamic balancing (G6.3 / G2.5) as a non-compulsory feature: the stability under high-speed or heavy load situations is significantly enhanced, hence, the motor overheating and bearing wear are prevented.
Suitable Equipment：
This machinery Is exactly what Is needed for input shafts of the motors, gearboxes, small and medium industrial drive shafts, and general factory machinery.
Such an instrument Is the core of the widest range of industries and, during the years, It has shown great performance.
The mining industry: shock-loaded drives, e.g. crushers, conveyors,etc.
Applications:
Metallurgy:Steel rolling lines and other high-temperature continuous operations.
Pumps: Water, oil, and slurry pumps—working to reduce the initiation of start/stop cycles.
Machining Equipment: Lathes, milling machines, and general processing units.
Automation Lines: Conveyors, packaging machines, assembly stations.
Fans & Compressors: Also, good vibration damping to prolong the life of bearings and motors.
These usages are the result of the long-term customer feedback that we have received in various industries.
Service Guarantee：
We can provide the following advantages to our worldwide industrial clients of mounting comfort, technical support and after-sales service:
Selection support: Our engineers will find out the perfect model based on the actual working conditions, torque, and shaft size.
Personalization: You can personalize everything from the flange dimensions and bore size to materials, dynamic balance, and keyway.
2D/3D Design: Helps both in construction and installation verification.
On-time delivery: Small orders can be done quickly; Bulk orders have a strong price advantage.
Always available: Whenever you need, we are here to solve your technical or application issues.
Complete package: Material certificates, heat-treatment reports, CO, FORM E, and more, are there for the export.
Production Capability：
We have with us long-term clients from the mining, metallurgy, and general machinery manufacturing sectors, who are highly repeat-order, which is the proof of our products' reliability.
Factory Size: 5,000㎡ machining workshop
The equipment: The full lineup of CNC turning, milling, boring, and planing is ready
Maximum Machining Size: The diameters can be up to 1500 mm
Annual Production Capacity: Over 3,000 jaw couplings
Quality Control: Raw material inspection → Full machining check → Dynamic balance → Final testing.
FAQ：
Q1: Can you manufacture products based on my designs?
Yes, we are an OEM/ODM factory that supports manufacturing based on your drawings or samples.
Q2: What is the largest size you can produce?
We can make a coupling with a diameter from 800 to 1500 mm and a weight of 1-3 tons depending on the structure.
Q3: Is it possible for you to perform a heavy-load dynamic balancing?
Yes, both G6.3 and G2.5 can be applied for heavy-duty or high-speed operations.
Q4: Are you able to recommend the suitable model of my machine?
Of course, Our field engineers will be able to recommend the best solution based on torque, speed, and mounting requirements.
